Crystal marble like high qulality rubber floor for metro station, airport,

  • Category:Rubber Flooring
  • Views:868
  • Product Manual:Crystal marble rubber flooring
BASIC INFO

Rubber floor





Technical specification
DESCRIPTION STANDARD RESULT
Total thickness EN428 3.0mm~8.0mm
Thickness of wear layer EN429 0.20mm~0.7mm

Dimension (Wood)

Dimension (Mixed Wooden pattern)

EN426 101.6x 914.4 mm (4"*36" )
152.4 x 914.4mm (6"*36" )
152.4*1219.2 mm (6"*48" )
184.15*1219.2 mm(7"*48" )
Dimension (Marble, Carpet) EN426 457.2 x 457.2mm (18"*18" )
457.2 x 914.4 mm (18"*36")
CLASSIFICATION
Norm/Product specification EN649 GB/T 11982.1-2005
Fire rating EN 13 501-1 Bfl-s1
Fire rating GB 8624-2012 b1(B-s1,t0)
Toxic testing GB 18586-2001 Pass
REACH (163 SVHC) SGS SVHC Pass
ROSHS RoSHS IEC Pass
RoHS EN71-3 Pass
Slip resistance wet DIN 51 130 R9
PERFORMANCE
Abrasion resistance EN 660.2 ≤2.0mm
Abrasion group EN 649 T (group)³
Dimensional stability EN 434 ≤0.4%
Residual indentation EN 433 0.02mm
Thermal conductivity EN 12 524 0.25W/ (m.K)
Color fastness EN 20 105 - B02 ≥ 7 degree
Dimensional stability after exposure to heat (horizontal) GB/T 11982.1-2005 0.07mm
Dimensional stability after exposure to heat (vertical) GB/T 11982.1-2005 0.19mm
Peel strength (horizontal) GB/T 11982.1-2005 92.99N/50mm
Peel strength (vertical) GB/T 11982.1-2005 90.23N/50mm
TVOC TVOC* ISO 16000-9 Pass
Formaldehyde ISO 1600-9 : 2006 ND
Acetaldehyde ISO 1600-9 : 2006 ND






Items Discription
Size (available) 6" x 36" / 7"X48" / 9" x 48"
Thickness (available) 4.0mm / 4.2mm / 5.0mm/ 7.0mm (WPC)
Wear layer (available) 0.3mm / 0.5mm / 0.7mm
Surface treatment UV coated with matt finish
Soft base pad EVA, IXPE, or Soft wood sheet will be stick on the bottom to reduce the acoustic and increase the foot softy feeling
Base core LVT, SPC, and WPC is different with the base core material
Installation Unilin Click ( Standard) or Valinge Click
Features Waterproof / Anti -slip / Wear-resistance / Fire-resistance / Sound barrier
Advantages Easy click to install








About IPAUL


IPAUL are fully committed to develop, produce, sell and install PVC resilient flooring (PVC Floor/ Vinyl Resilient Floor/Homogeneous PVC Floor, LVT/LVS/SPC/WPC). We provide excellent flooring products and service for our customer.

Our head office located in Guangzhou, products sell well all over China, and we also export our products to The Americas, Europe, Southeast Asian country, Middle East, Africa and so on. Our flooring has rich colors, good performance, It is well received by our customers. With a fully functional workshop, advanced PVC plastic floor production equipment and product testing center, then a full range of strict quality control is carried out for the production process of the product.

We actively advocate the “low-carbon and environmental building materials”. Our PVC roller sheet, PVC tiles and rubber flooring are widely use for medical institution, educational services, office place,

Residential area, airport, hotel, gym, library, club, shopping mall, factory and so on. It brings comfortable space for the customers to learn, work, exercise and live.

IPAUL floors have been fully recognized and affirmed by the market since launch. It has won a series of awards such as "Top ten brands of Chinese resilient flooring industry", "China's famous brands", "the first choice brand of green environmental protection", "the first choice brand of national engineering building materials" and "AAA grade Chinese quality credit enterprise". Our products had passed the European CE and SGS certification, ISO9001 quality management certification and ISO14001 environmental management system certification. IPAUL has become the supervision unit of Guangdong building materials industry association, and the executive director unit of China's resilient floor industry, which has a high reputation in the floor industry.

IPAUL has always been to "professional and outstanding" the management idea of serving our customers, cooperate with our new and old customers hand in hand to win a better future, our company all staff sincerely welcome all kinds friend inquiry, negotiation, cooperation and communication. And strives to make unremitting efforts to create an international famous national brand for IPAUL PVC resilient floor.
