Sports PVC Floor
IPAUL offer the sports PVC floor for sport center application. We can make different texture, Sport PVC floor have different types for different application.
The professional PVC sports floor has excellent and stable ball resilience, and its surface energy would moderately deformed when it is impacted, like a sealed mattress with air inside. When it is wrestling or slipping, the closed foam back layer provide cushion to achieve minimum sports injuries.
Athletes absorb vibration during exercise and return exercise energy to improve exercise performance.
IPUAL professional PVC sports flooring
- Glass fiber reinforced layer
- Glass fiber grid stabilization layer
- UV surface anti-fouling and wear-resistant treatment
IPUAL Sports Floor provides professional, comfortable and safe flooring.
The product is suitable for: badminton courts, table tennis courts, tennis courts, basketball courts, volleyball courts, handball courts, multi-sport competition courts and gymnasiums, kindergartens, dance floor-specific floors, shopping malls, schools, and office buildings.
A total of 30 designs and colors, Model number: BL8601-BL8639
Including 2 wood grains, 2 grid patterns, 4 hammered patterns, 6 lychee patterns, 1 snakeskin pattern, 3 diamond patterns, 2 sand grain patterns and 10 solid color dance floors.
Technical specification | ||
DESCRIPTION | STANDARD | RESULT |
Total thickness | EN428 | 3.0mm~8.0mm |
Thickness of wear layer | EN429 | 0.20mm~0.7mm |
Dimension (Wood) Dimension (Mixed Wooden pattern) |
EN426 | 101.6x 914.4 mm (4"*36" ) |
152.4 x 914.4mm (6"*36" ) | ||
152.4*1219.2 mm (6"*48" ) | ||
184.15*1219.2 mm(7"*48" ) | ||
Dimension (Marble, Carpet) | EN426 | 457.2 x 457.2mm (18"*18" ) |
457.2 x 914.4 mm (18"*36") | ||
CLASSIFICATION | ||
Norm/Product specification | EN649 | GB/T 11982.1-2005 |
Fire rating | EN 13 501-1 | Bfl-s1 |
Fire rating | GB 8624-2012 | b1(B-s1,t0) |
Toxic testing | GB 18586-2001 | Pass |
REACH (163 SVHC) | SGS SVHC | Pass |
ROSHS RoSHS | IEC | Pass |
RoHS | EN71-3 | Pass |
Slip resistance wet | DIN 51 130 | R9 |
PERFORMANCE | ||
Abrasion resistance | EN 660.2 | ≤2.0mm |
Abrasion group | EN 649 | T (group)³ |
Dimensional stability | EN 434 | ≤0.4% |
Residual indentation | EN 433 | 0.02mm |
Thermal conductivity | EN 12 524 | 0.25W/ (m.K) |
Color fastness | EN 20 105 - B02 | ≥ 7 degree |
Dimensional stability after exposure to heat (horizontal) | GB/T 11982.1-2005 | 0.07mm |
Dimensional stability after exposure to heat (vertical) | GB/T 11982.1-2005 | 0.19mm |
Peel strength (horizontal) | GB/T 11982.1-2005 | 92.99N/50mm |
Peel strength (vertical) | GB/T 11982.1-2005 | 90.23N/50mm |
TVOC TVOC* | ISO 16000-9 | Pass |
Formaldehyde | ISO 1600-9 : 2006 | ND |
Acetaldehyde | ISO 1600-9 : 2006 | ND |
Items | Discription |
Size (available) | 6" x 36" / 7"X48" / 9" x 48" |
Thickness (available) | 4.0mm / 4.2mm / 5.0mm/ 7.0mm (WPC) |
Wear layer (available) | 0.3mm / 0.5mm / 0.7mm |
Surface treatment | UV coated with matt finish |
Soft base pad | EVA, IXPE, or Soft wood sheet will be stick on the bottom to reduce the acoustic and increase the foot softy feeling |
Base core | LVT, SPC, and WPC is different with the base core material |
Installation | Unilin Click ( Standard) or Valinge Click |
Features | Waterproof / Anti -slip / Wear-resistance / Fire-resistance / Sound barrier |
Advantages | Easy click to install |
BL8601
BL8602
About IPAUL
IPAUL are fully committed to develop, produce, sell and install PVC resilient flooring (PVC Floor/ Vinyl Resilient Floor/Homogeneous PVC Floor, LVT/LVS/SPC/WPC). We provide excellent flooring products and service for our customer.
Our head office located in Guangzhou, products sell well all over China, and we also export our products to The Americas, Europe, Southeast Asian country, Middle East, Africa and so on. Our flooring has rich colors, good performance, It is well received by our customers. With a fully functional workshop, advanced PVC plastic floor production equipment and product testing center, then a full range of strict quality control is carried out for the production process of the product.
We actively advocate the “low-carbon and environmental building materials”. Our PVC roller sheet, PVC tiles and rubber flooring are widely use for medical institution, educational services, office place,
Residential area, airport, hotel, gym, library, club, shopping mall, factory and so on. It brings comfortable space for the customers to learn, work, exercise and live.
IPAUL floors have been fully recognized and affirmed by the market since launch. It has won a series of awards such as "Top ten brands of Chinese resilient flooring industry", "China's famous brands", "the first choice brand of green environmental protection", "the first choice brand of national engineering building materials" and "AAA grade Chinese quality credit enterprise". Our products had passed the European CE and SGS certification, ISO9001 quality management certification and ISO14001 environmental management system certification. IPAUL has become the supervision unit of Guangdong building materials industry association, and the executive director unit of China's resilient floor industry, which has a high reputation in the floor industry.
IPAUL has always been to "professional and outstanding" the management idea of serving our customers, cooperate with our new and old customers hand in hand to win a better future, our company all staff sincerely welcome all kinds friend inquiry, negotiation, cooperation and communication. And strives to make unremitting efforts to create an international famous national brand for IPAUL PVC resilient floor.
For more products, you can refer the table in the following:
brand | PVC Commercial Flooring description |
Wear Layer (WL) |
Bottom Lay | WebPages |
GRETEL |
Non Directional Homogenous PVC Floor Thickness: 2/2.5/3mm; Size: 20m (L)* 2m (W) |
UV Coating | Compact | Click here |
ARIT |
Directional Homogenous PVC Floor Thickness: 2/2.5/3mm; Size: 20m (L)* 2m (W) |
UV Coating | Compact | Click here |
LAIPO |
2.0 mm Resilient PVC Flooring Thickness: 2.0 mm; Size: 20m (L)* 2m (W) |
UV Coating 0.35 mm WL |
Compact | Click here |
JIAPO |
2.0 mm Resilient PVC Flooring Thickness: 2.0 mm; Size: 20m (L)* 2m (W) |
UV Coating 0.35 mm WL |
77: Compact 22: Little Foaming |
Click here |
YAPO |
3.0 mm Resilient PVC Flooring Thickness: 3.0 mm; Size: 20m (L)* 2m (W) |
UV Coating 0.5 mm WL |
Little Foaming | Click here |
HAPO |
2.6 mm Resilient PVC Flooring Thickness: 2.6 mm; Size: 20m (L)* 2m (W) |
UV Coating 0.5mm WL |
Little Foaming | Click here |
YUEPO |
2.0 mm Resilient PVC Flooring Thickness: 2.0 mm; Size: 20m (L)* 2m (W) |
UV Coating 0.35 mm WL |
Foaming | Click here |
LIPO |
1.8mm Resilient PVC Flooring Thickness: 1.8 mm; Size: 20m (L)* 2m (W) |
UV Coating 0.25 mm WL |
Compact | Click here |
NAPO |
1.6 mm Resilient PVC Flooring Thickness: 1.6 mm; Size: 20m (L)* 2m (W)
|
UV Coating 0.15 mm WL |
Compact | Click here |
KAPO |
3.5mm/4.5mm sports vinyl flooring
Thickness: 3.5 mm; Size: 20m (L)*1.5m/1.8m (W)
Thickness: 4.5 mm; Size: 15m (L)* 1.5m/1.8m (W) |
UV Coating 1 mm WL 1.2mm WL |
Foaming |
Click here |
